MultitopPro - multipoint lock

Product Description

Multitop Pro is a lock for aluminium and steel doors which effectively corrects heat distortion of the door and controls door status, also offering maximum performance when protecting against forced entry (European standard EN12209) and control of door status.

Closing is "guaranteed" over time thanks to a gear mechanism and deadbolts with a rounded design which correct heat distortion of the door due to sudden changes in temperature.

No draughts but energy savings thanks to the hermetic seal.

Protection against forced entry.
The deadbolts are independent of the central mechanism: in the event of forced entry, the intruder has to force every single locking point.
Sturdy deadbolts: 12 mm thick, 25 mm projection and hook in hardened steel incorporated into the deadbolt: resists both thrust (thickness) and widening of the profile with a crowbar.
Protected with hardened steel plates.
Lock can be fitted with up to 5 locking points (on two-leaf doors) and cylinder protective rose.

Door status always under control with the lateral deadbolt kits.
A micro switch triggers off a light which goes on every time the door is not securely locked (deadbolts engaged).

Security for 3 metre entrance doors.
An extension that reaches up to 3 metres can be added to the faceplate and a deadbolt can be added to increase the overall security of the large entrance door (along the whole length).

Greater security for doors and large entrance doors which are not deadbolted.
Dead-locking latch bolt: when the door is locked, the withdrawal of the deadbolt automatically blocks the latch bolt (electric version).

Protected gears.
Cases are enclosed to eliminate the possibility of damage during installation and to stop dirt and dust getting into the gears as this can prevent correct operation of the lock.

Easy and economical to install.
Reversible and adjustable latch bolt to ensure ideal coupling with the strike plate.

Personalised level of security. Choose the cylinder which best meets your needs.

One key opens several doors. With master key systems, you can use one key to open several different accesses, such as doors, gates and garages.

Key comfort. Key is small in size and easy to use.



Extended bolt with additional divertor for doors up to 3 m high, energy saving: the gear mechanism with rounded deadbolt effectively corrects heat distortion on doors, deadbolts 12 mm thick with anti-cut protection, dead-locking latch bolt when the deadbolt is not inserted. Certified up to the highest Security grade, grade 7, of the European standard pr EN 15685.

Features

TECHNICAL FEATURES

  • Cylinder protective rose can be installed
  • Dead-locking latch bolt: when the door is locked, the withdrawal of the deadbolt automatically blocks the latch bolt (only on electric version)
  • 15.5 mm case so the lock adapts perfectly to any kind of profile
  • Cases are enclosed to eliminate the possibility of damage during installation and to stop dirt and dust getting into the gears
  • Interchangeable latch bolt and roller, even when the lock is installed
  • Interchangeable with the corresponding locks with swing bolt

Supplied as standard

  • Pair of nylon protective roses
  • Fixing screws for lock and cylinder
  • Instruction sheet

On request

  • Euro profile cylinder
  • Specific strike plates
  • "MODULAR" roller assembly
  • Cylinder protective rose
  • Mechanical button
  • Euro profile cylinder
  • Specific strike plates
  • Roller accessory �MODULARE�
  • Cylinder protective rose
  • Mechanical button
  • Standards

    • Certified according to European standard EN 12209:03 grade 6 Security (1000 kg lateral thrust and 600 kg front load)
    • Suitable for EN1627:2011 certified doors up to resistance class WK/RC 4 (grade 6)
